7.5W/mk Thermal Pads Replacement CPU/GPU Thermal Pad 3.5mm Electric Laptop Heatsink

Name: 75Wmk Thermal Pads Replacement CPUGPU Thermal Pad 35mm Electric Laptop Heatsink
Brand: ZIITEK
Price: 1 USD

Wholesale 7.5W/mk Thermal Pads Replacement CPU/GPU Thermal Pad 3.5mm Electric Laptop Heatsink from china suppliers

Brand Name : ZIITEK

Model Number : TIF7140PES thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000pcs

Price : negotiation

Supply Ability : 100000pcs/day

Delivery Time : 3-5 work days

Packaging Details : 1000pcs/bag

Name : 7.5W/mk Thermal Pads Replacement CPU/GPU Thermal Pad 3.5mm Electric Laptop Heatsink

Applications : CPU PC GPU

Material : Ceramic filled silicone elastomer

Thermal conductivity : 7.5W/m-K

Thickness : 3.5mmT

keyword : Thermal Pads

Contact Now

7.5W/mk Thermal Pads Replacement CPU/GPU Thermal Pad 3.5mm Electric Laptop Heatsink

Ziitek TIF7140PES is recommended for applications that require a minimum amount of pressure on components. The viscoelastic nature of the material also gives excellent low-stress vibration dampening and shock absorbing characteristics. Ziitek TIF140PES is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.

TIF700PES-(TDS-EN-REV04).pdf

7.5W/mk Thermal Pads Replacement CPU/GPU Thermal Pad 3.5mm Electric Laptop Heatsink

Features

> Good thermal conductive: 7.5 W/mK

> Thickness: 3.5 mmT

> hardness:10

> Colour: gray

> Available in varies thicknesses
> Broad range of hardnesses available
> Moldability for complex parts

Applications

> Semiconductor automated test equipment (ATE)
> CPU
> Display card
> Mainboard/mother board
> Notebook
> Power supply

Typical Properties of TIF7140PES Series
Color	Blue	Visual	Composite Thickness	Thermal Impedance@10psi (℃-in²/W)
Construction & Compostion	Ceramic filled silicone elastomer	***	10mils / 0.254 mm	0.16
			20mils / 0.508 mm	0.20
Specific gravity	3.2 g/cc	ASTM D297	30mils / 0.762 mm	0.31
			40mils / 1.016 mm	0.36
Thickness	3.5mmT	***	50mils / 1.270 mm	0.42
			60mils / 1.524 mm	0.48
Hardness	10	ASTM 2240	70mils / 1.778 mm	0.53
			80mils / 2.032 mm	0.63
Thermal conductivity	7.5W/mk	ASTMD5470	90mils / 2.286 mm	0.73
			100mils / 2.540 mm	0.81
Continuos Use Temp	-40 to 160℃	***	110mils / 2.794 mm	0.86
			120mils / 3.048 mm	0.93
Dielectric Breakdown Voltage	≥5000 VAC	ASTM D149	130mils / 3.302mm	1.00
			140mils /3.556 mm	1.08
Dielectric Constant	5~6MHz	ASTM D150	150mils / 3.810 mm	1.13
			160mils / 4.064 mm	1.20
Volume Resistivity	≥ 3.5X10¹² Ohm-cm	ASTM D257	170mils / 4.318 mm	1.24
			180mils / 4.572 mm	1.32
Fire rating(no.E331100)	V-0	equivalent UL	190mils / 4.826 mm	1.41
			200mils / 5.080 mm	1.52
Thermal conductivity	7.5 W/m-K	GB-T32064	Visua l/ ASTM D751	ASTM D5470

Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.
